Data pipelines are a series of interconnected steps or processes that are used to extract, transform, and load (ETL) data from various sources into a target destination, such as a database or a data warehouse. Data pipelines are commonly used in data integration scenarios where data needs to be collected from multiple sources, transformed into a desired format, and loaded into a centralized storage for further analysis or processing.

Designing data pipelines with PostgreSQL and Python involves several key steps, including data extraction, transformation, and loading (ETL). PostgreSQL is a powerful open-source relational database management system (RDBMS) that supports complex data handling and retrieval, while Python is a versatile programming language with extensive libraries for data manipulation and integration.

For the purpose of this data digest, some of the codes will be written in Jupyter notebook and visual studio code on how to leverage python to run some queries with key highlights on the following sub-topics:

• Python libraries involved to run SQL queries on a PostgreSQL Database
• Create a connection with your PostgreSQL database
• Reading tables from PostgreSQL Database
• Save specific query back to the PostgreSQL Database
• Create, insert, read, update and delete table with Python in PostgreSQL database using VS code IDE

Instructor: Chimdiadi Catherine Orji

Let’s get started…

This is the link to the PostgreSQL Database that will be used in this data gist.

Libraries involved in Python to run SQL queries on a PostgreSQL Database

when working with PostgreSQL in python, some library are required which includes - psycopg2, pandas and sqlachemy.

• First, import the following library highlighted above.

import psycopg2
import pandas as pd
from sqlalchemy import create_engine

Create a connection with your PostgreSQL database

Note: To create this connection, leverage the create engine imported from the sqlalchemy. The user, password and name of database will be required to successfully create the connection.

connection = create_engine("postgresql + psycopg2://{user}:{pw}@localhost/{db}".format(user = "postgres",pw = "*******", db = "postgres"))

Reading tables from PostgreSQL Database

• Reading a table using read_sql to return actor table in the database schema and present the result in a dataframe - since this is done using pandas.

df = pd.read_sql("SELECT * FROM actor", connection)
df.head()

The result of this query will be a dataframe that looks like this :

• Reading a table using read_sql_table to return the address table in the database schema in postgreSQL

dff = pd.read_ sql_read_table("address", connection)
dff.head()

The result of this query will be a dataframe that looks like this :

• Reading a table using read_sql_query to return the address table in the database schema in postgreSQL.

Note: For this, it will require creating a query first and inserting the query in tandem with the connection in the pandas function. This will be used on the same address table

query = "SELECT * FROM address"

data = pd.read_sql_query(query, connection)
data.head()

The result of this query will be a dataframe that looks like this :

• Writing more complex joins queries from the Jupyter notebook that left joins the record in the film table to inventory table on “film_id” column to see the films that are not present in the inventory table.

query = """ SELECT film.film_id,
									title,
									inventory_id,
									store_id
					FROM film
					LEFT JOIN inventory ON inventory.film_id = film.film_id
					WHERE inventory.film_id is NULL"""

data = pd.read_sql_query(query, connection)
data.head()

The result of this query will be a dataframe that looks like this :

Save specific query back to the PostgreSQL Database

• To save the result from the query above into a table in the scheme on postgreSQL from python, one can leverage the code below and the table will be replicated on the database. I will be saving this table with “film_invent”


data.to_sql(“film_invent”, connection, if exists ="fail")

Create, insert, read, update and delete table with Python in PostgreSQL database using VS code IDE

In Python, "try-except" is a way to handle exceptions or errors that may occur during the execution of a program. Exceptions are events or errors that occur during the normal flow of program execution, and they can disrupt the normal execution of the program.

The "try" block is used to enclose a section of code that may raise an exception. If an exception occurs within the "try" block, the code execution is immediately transferred to the corresponding "except" block that handles that specific exception. The "except" block contains the code that will be executed to handle the exception.

The “finally” block is also optional and can be used with try and except. The code within the finally block is always executed, regardless of whether an exception occurred or not. It is typically used to specify cleanup operations that must be performed, such as closing a file or releasing resources, regardless of whether an exception occurred or not.

• Creating table in PostgreSQL with python from VS Code IDE

Note: You can copy and post the code in your VS code IDE

import psycopg2
from psycopg2 import Error

try:
# create connection
connection= psycopg2.connect(
		host = "localhost", user = "postgres", password = "********", database = "postgres"
)

# cursor object
cursor = connection.cursor()

# drop table if exist using the execute method()
cursor.execute("DROP TABLE IF EXISTS student")

# query - create table
query = """CREATE TABLE student(
				student_id INTEGER PRIMARY KEY,
				first_name VARCHAR(20),
				last_name VARCHAR(20),
				age INTEGER
)
"""

	# Execute query
	cursor.execute(query)


	# Commit changes
	connection.commit()

	# print a message
	print("Table created successfully")


except Error as e:
	# Rollback changes
	connection.rollback()
	print("Error: creating table")

finally:
	connection.close()
	print("connection closed")


• Insert new rows into created table in PostgreSQL with python from VS Code IDE

try:
	# create connection
	connection= psycopg2.connect(
			host = "localhost", user = "postgres", password = "********", database = "postgres")

	# cursor object
	cursor = connection.cursor()

	# query insert
	# create a placeholder to insert values

	query ="""INSERT INTO student(student_id, first_name, last_name, age)
						VALUES(%s, %s, %s, %s)
	"""

	# create an insert list

	records = [((1, "Emeke", "Jude", 23)
							(2, "Ayomide", "Emmanuel", 25))]


	# Execute query
		cursor.executemany(query, records)

	# commit changes
	connection.commit()

	# print a message
	print("rows inserted successfully")

except Error as e:
	connection.rollback()
	print(e)
	print("Error inserting table")

finally:
	connection.close()
	print("connection closed")

• Read data from created table in PostgreSQL with python from VS Code IDE with certain condition

Note: Here, I will be creating a function that gets the name of actors and bring out specific information with respect to the name

def getActor(name):
	try:
		connection= psycopg2.connect(
		host = "localhost", user = "postgres", password = "********", database = "postgres")

	# cursor object
	cursor = connection.cursor()

	# write query
	# create a placeholder to insert values
	query = "SELECT * FROM actor WHERE first_name = %s"

	# Execute query
		cursor.executemany(query, (name, ))

	# create record
	record = cursor.fetchall()
	for row in record:
		print("actor_id", row[0])
		print("first_name", row[1])
		print("last_name", row[2])
		print("last_update", row[3], "\n")

except Error as e:
	print("Error reading table")

finally:
	connection.close()
	print("connection closed")


• Let’s get actor with the name “Nick”. This will be done by passing the name into the function created.

getActor("Nick")

The result of this query will look like this :

• Update specific table records in PostgreSQL with python from VS Code IDE with certain condition

try:
	# create connection
	connection= psycopg2.connect(
			host = "localhost", user = "postgres", password = "********", database = "postgres")

	# cursor object
	cursor = connection.cursor()

	# Execute query
	query = "UPDATE student SET age = 27"

	cursor.execute()

	# commit changes
	connection.commit()

	# check for update
	cursor.execute("SELECT * FROM students")

	for row in record:
		print("student_id", row[0])
		print("first_name", row[1])
		print("last_name", row[2])
		print("age", row[3], "\n")

	# print message
	ptint("successful update")

except Error as e:
	connection.rollback()
	print("Error : updating")

finally:
	connection.close()
	print("connection closed")

Note: This code updates the age from 24 to 27 and it is effected in the PostgreSQL database. The result looks like this in the VS IDE terminal.

• Delete specific table records in PostgreSQL with python from VS Code IDE with certain condition

try:
	# create connection
	connection= psycopg2.connect(
			host = "localhost", user = "postgres", password = "********", database = "postgres")

	# cursor object
	cursor = connection.cursor()

	# write your query
	query = "DELETE FROM student WHERE student_id = 1"

	# Execute your query
	cursor.execute(query)

	# Check for delete
	cursor.execute("SELECT * FROM student")

	record = cursor.fetchall()

	for row in record:
		print("student_id", row[0])
		print("first_name", row[1])
		print("last_name", row[2])
		print("age", row[3], "\n")

	# print message
	print("deleted successfully")

except Error as e:
	connection.rollback()
	print("Error : deleting")

finally:
	connection.close()
	print("connection closed")

Conclusion

Python provides powerful libraries that allow you to interact with PostgreSQL databases and perform various operations like running SQL queries, creating connections, reading tables, saving query results, and performing CRUD (Create, Read, Update, Delete) operations on tables.

With the help of these libraries and tools like Jupyter notebook and Visual Studio Code IDE, you can leverage the flexibility and versatility of Python to efficiently work with PostgreSQL databases in your data analysis or application development tasks. Whether you are a data scientist, data engineer, or software developer, mastering the use of Python for PostgreSQL interactions can greatly enhance your ability to work with databases effectively and efficiently.
